Humidity 0 to 95% relative humidity
(non-condensing)
5ft Multiple drops to unyielding steel
plate, -10 to +50C temperature range and
4ft drop at -20°C
Testing done per Honeywell drop specification
Exceeds 1,000 (1.0m) tumbles per IEC
60068-2-32 specification
ESD
± 15KV Air and ± 8KV Direct
Environmental Sealing
Independently
certified to meet IP67 standards for moisture
and particle intrusion
SYSTEM ARCHITECTURE
Processor
2.26GHz Qualcomm Snapdragon
801 quad-core
Operating System
Windows Embedded 8.1 Handheld,
Android 4.4.4 KitKat
Memory
2 GB RAM, LP-DDR3 @ 800MHz (min)
POP stack memory / 16 GB eMMC NAND Flash
Display
4.66” TFT Color LCD with Backlight,
720p HD, >400nits, Outdoor Viewable
Touch Panel
Rugged Multi Input Capacitive Touch
Keypad
Side Scan triggers, Volume up / down,
Camera, Power button
Audio
Speaker, T3 / M3 HAC Compliant
Receiver, Microphones
I/O Ports
Custom IO connector
Camera
8.0 megapixel color camera with
autofocus and advanced software features for
better image quality.
Sensors
Ambient Light Sensor, Proximity
Sensor, Accelerometer, Gyroscope,
Magnetometer, Pressure Sensor
Storage Expansion
Micro SD Card
SDHC/SDIO compliant. Please check with
your Honeywell representative for available
qualified card options
Battery
Li-Ion, 3.6V, 3950mAh with integrated
fuel gauge
Hours of Operation
12+ Hours
Decode Capabilities
Honeywell Slim engine 2D
scanner capable of decoding standard 1D and
2D bar code symbologies
Development Environment
Honeywell SDKs
for Android and Windows
HSM Application Software
Honeywell
Powertools and Demos
Warranty
1 year factory warranty
WIRELESS CONNECTIVITY
WWAN:
WWAN Radio (ATT / VZW / NA)
LTE (4G) Quad Band (Bands 2, 4, 5, 17),
UMTS/HSPA+ (3G) Quad Band
(Bands 1, 2, 5, 8), GSM/GPRS/EDGE Quad-Band
(850/900/1800/1900MHz) Dual Band
1xRTT/EV-DO (Bands BC0, BC1)
WWAN Radio (EU) LTE (4G) Tri-Band
(Bands 3, 7, 20), UMTS/HSPA+ (3G) Dual Band
(Bands 1,5, 8) and GSM/GPRS/EDGE
(Quad Band (850/900/1800/1900MHz)
WLAN:
IEEE 802.11 a/b/g/n/ac; Wi-FiTM certified
WLAN Security (WE8.1H):
OPEN,WEP,WPA/WPA2
(Personal and Enterprise)
Supported EAP:
TLS, PEAP-MS-CHAP-V2, TTLS
WLAN Security (Android):
OPEN,WEP,WPA/WPA2 (Personal and Enterprise)
Supported EAP:
TLS, PEAP, TTLS, PWD, FAST, LEAP
CCX Version 4 certified (Android only)
Bluetooth:
V4.0 Bluetooth Qualification Body
(BQB) Cert. Co-existence with 802.11a/b/g
(IEEE 802.15.2 PTA) Internal Antenna
Supported Bluetooth Profiles:
HFP, PBAP, A2DP,
AVRCP, OPP only
NFC:
Integrated Near Field Communication
VoIP (stationary/non-roaming):
Supported
VPN:
IPSec V4/L2TP, PPTP
Push to Talk (PTT):
Supported
GPS Supported Protocols:
GNSS Receiver for
GPS and GLONASS
